Bafang Display DP-C18 Gazelle ,, Cortina ,, inz.
Geschikt voor Bafang BBS01, BBS02, BBSHD, Bafang max drive en alle E-Drive naafmotor sets.
36V/43V/48V DP-C18 Display voor Bafang middenmotor en voorwielmotor met controller Bafang protocol.
Features:
DP-C18 Colorful E-Bike Display
Screen Size: 3.2 inch
Voltage: DC 36V/43V/48V
Display speed Limit: 90km/h
Brightness: 5-level (10%,30%,50%,75%,100%)
PAS Speed Level: 0-5 level
Show Battery level, speed, distance, power, and more
USB Output: 5V 500mA
Protocol: UART
High-contrast IPS Colorful Matrix Display
Compatible with BBS01, BBS02 and BBSHD
Waterproof: IP65
Operation Temperature: -20~45?
Storage Temperature: -30~70?
Suitable Handlebar Diameter: f22.5/25.4/31.8mm
Press Key cable length: 24.5cm
Power cable length: 46cm
Plug Type: 5-pin waterproof quick release female
Size: (W)62 x (H)96mm (2.44×3.78 inch)
Weight: 350g
